View technical drawing

20602 3-point electric lock with panic bar

Rim electric lock equipped with 3 side points and with a push bar allowing an emergency exit.

Features

3-point side rim motorized electric lock with push bar for free exit.
Integrated management electronic card for autonomous operation
Free exit even in the event of voltage failure thanks to its panic bar.
Exit push button and integrated indicator light.
Anti-burglary: 3 anti-sawing bolts.
Automatic relocking on closing.

Motorized

Suggested application of use

Education, Financial, Hospitals, Industrial, Medium to Large Sized Businesses, Offices, Public Buildings, Airports, Small to Medium Sized Businesses

Specifications

Technical features

Lock Application Type	Rim Lock
Locking Points	3 points
Locking Type	Round Cylinder Deny, European Profile Cylinder
Closing Mechanism	Motorised
Locking Elements	Deadbolt
Reversible	No
Lock Handing	Right-Left Push
Operation Mode	Fail-safe
Standard Warranty	1 Year

Configuration

Optional Finishes	RAL
Cylinder Length	Depends on the thickness of the door
Case Height (mm)	2500
Case Depth (mm)	41
Case Material	Brushed Stainless Steel
Case Finish	Stainless Steel
Deadbolt Material	Stainless Steel
Deadbolt Dimension	Diameter 22mm
Deadbolt Throw (mm)	22
Forend Material	Stainless Steel
Forend Finish	Brushed Stainless Steel
Strike Depth (mm)	41
Strike Height (mm)	2500
Power Type	Wired
Current Consumption	Consommation en veille : 30mA sous 12VDC, Consommation maximale : 2A sous 12VDC
Voltage Range	12V
Voltage Type	DC
